Nectre BIG Bakers Oven

Nectre BIG Baker's Oven

Warming your home and tummy both at the same time. The Nectre Big Bakers Oven brings heating together with traditional wood fire stove cooking. A powerful radiant wood heater that can warm a large living space up to 200m2. You will feel comfortable and warm during the coldest winter days and evenings.

• Oven temperature thermometer
• Cast iron door with ceramic glass
• Stay cool spring handle
• Optional water booster available

Specifications

Approximate Heating Area	Up to 200m2
Maximum log width	445mm
Weight	220kg

Dimensions
Legs Model: 690mm (W) x 828mm (H) x 565mm (D)
Base Width: 500mm

Heater Clearances

Rear to Wall - 125mm (square to walls)

Side to Wall - 325mm (square to walls)

Rear Corner to Wall - 275mm (corner installation)

Manuals:

Nectre Big Bakers Oven Installation Instructions.pdf

Nectre Big Bakers Oven Operating Instructions.pdf

Flue Options

To complete any wood heater installation a flue kit and flashing will be required. These are available for purchase as standard kits online which will suit straightforward vertical single-story applications. Depending on your site specifics you may also need a hearth or other components that aren't available on our website.

We have heater experts available in store to give advice for wood heater installations so if you have any questions call 1300 300 227 or drop into your local outlet.

Standard Flue Kit	Includes
SWH-6101	· Anti-down draught hat SS · 2 x 10"galvanised flue lengths · 2 x 8"galvanised flue lengths · 2 x 6"SSflue lengths · 10"ceiling ring galvanised · 2 x 6"black painted SS flue lengths · SS half shield
SWH-6136	· Anti-down draught hat SS · 2 x 10"galvanised flue lengths · 2 x 8"galvanised flue lengths · 4 x 6" SS flue lengths · 10"ceiling ring galvanised · 2 x 8"black painted SS mesh flue length

Standard Flashing	Suits
DFE108B	Metal roof 170-355mm external flue
DNL108B	Tile roof 175-300mm external flue
