Original: $2,281.09
-65%$2,281.09
$798.38The Story
Nectre MK2 Wood Fire
The Nectre Mk2 is beautifully compact but yet powerful enough to heat around 185m2 of living area. With a choice of freestanding legs or a pedestal base to make sure your Mk2 fireplace perfectly complements your space and design tastes.
- Impressive heat output of up to 18kW
- Choice of freestanding legs or pedestal
- Heats up to 185m2
- Cast iron door with ceramic glass
Dimensions
Pedestal Model: 750mm (W) x 716mm (H) x 528mm (D)
Legs Model: 750mm (W) x 653mm (H) 528mm (D)
Heater Clearances
From Rear to Wall - 125mm (square to walls)
From Side to Wall - 450mm (square to walls)
From Rear Corner to Wall - 200mm (corner installation)
Compliance
The Nectre Mk2 has been designed and manufactured to exceed the strict AS/NZS 4013 standards for emissions of 1.5g /kg of fuel burnt and efficiency of 73%.
Specifications
| Heat Output | 18kW |
| Approximate Heating Area | Up to 200m2 |
| Efficiency | 73% |
| Emissions | 1.3g |
| Maximum log width | 475mm |
| Weight |
Legs Model - 140kg Pedestal Model - 160kg |
Manuals
Nectre MK2 Installation Manual.pdf
Flue Options
To complete any wood heater installation a flue kit and flashing will be required. These are available for purchase as standard kits online which will suit straightforward vertical single-storey applications. Depending on your site specifics you may also need a hearth or other components that aren't available on our website.
We have heater experts available in store to give advice for wood heater installations so if you have any questions call 1300 300 227 or drop into your local Tucker Barbecues outlet.
|
Standard Flue Kit |
Includes |
|
SWH-6101 |
· Anti-down draught hat SS · 2 x 10"galvanised flue lengths · 2 x 8"galvanised flue lengths · 2 x 6" SS flue lengths · 10"ceiling ring galvanised · 2 x 6"black painted SS flue lengths · SS half shield |
|
SWH-6136 |
· Anti-down draught hat SS · 2 x 10"galvanised flue lengths · 2 x 8"galvanised flue lengths · 4 x 6" SS flue lengths · 10" ceiling ring galvanised · 2 x 8" black painted SS mesh flue length |
|
Standard Flashing |
Suits |
|
DFE108B |
Metal roof 170-355mm external flue |
|
DNL108B |
Tile roof 175-300mm external flue |
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Description
Nectre MK2 Wood Fire
The Nectre Mk2 is beautifully compact but yet powerful enough to heat around 185m2 of living area. With a choice of freestanding legs or a pedestal base to make sure your Mk2 fireplace perfectly complements your space and design tastes.
- Impressive heat output of up to 18kW
- Choice of freestanding legs or pedestal
- Heats up to 185m2
- Cast iron door with ceramic glass
Dimensions
Pedestal Model: 750mm (W) x 716mm (H) x 528mm (D)
Legs Model: 750mm (W) x 653mm (H) 528mm (D)
Heater Clearances
From Rear to Wall - 125mm (square to walls)
From Side to Wall - 450mm (square to walls)
From Rear Corner to Wall - 200mm (corner installation)
Compliance
The Nectre Mk2 has been designed and manufactured to exceed the strict AS/NZS 4013 standards for emissions of 1.5g /kg of fuel burnt and efficiency of 73%.
Specifications
| Heat Output | 18kW |
| Approximate Heating Area | Up to 200m2 |
| Efficiency | 73% |
| Emissions | 1.3g |
| Maximum log width | 475mm |
| Weight |
Legs Model - 140kg Pedestal Model - 160kg |
Manuals
Nectre MK2 Installation Manual.pdf
Flue Options
To complete any wood heater installation a flue kit and flashing will be required. These are available for purchase as standard kits online which will suit straightforward vertical single-storey applications. Depending on your site specifics you may also need a hearth or other components that aren't available on our website.
We have heater experts available in store to give advice for wood heater installations so if you have any questions call 1300 300 227 or drop into your local Tucker Barbecues outlet.
|
Standard Flue Kit |
Includes |
|
SWH-6101 |
· Anti-down draught hat SS · 2 x 10"galvanised flue lengths · 2 x 8"galvanised flue lengths · 2 x 6" SS flue lengths · 10"ceiling ring galvanised · 2 x 6"black painted SS flue lengths · SS half shield |
|
SWH-6136 |
· Anti-down draught hat SS · 2 x 10"galvanised flue lengths · 2 x 8"galvanised flue lengths · 4 x 6" SS flue lengths · 10" ceiling ring galvanised · 2 x 8" black painted SS mesh flue length |
|
Standard Flashing |
Suits |
|
DFE108B |
Metal roof 170-355mm external flue |
|
DNL108B |
Tile roof 175-300mm external flue |
